iMark Microplate Absorbance Reader Instruction Manual
19
1: 400 nm 5:650nm
2:450nm 6:...nm
3:475nm 7:...nm
4:650nm 8:...nm
Filter
Day/Month/Year
16 / 05 / 01
Hour: Minutes
18 : 55
Date set
Enter Lab. name
Bio Rad Laboratories
↑
[ABC]
Lab. name
Filter Setting
Move the cursor to the desired position by using the Up, Down, and Right arrow keys.
Enter the filter wavelength on the selected position using the number keys.
If the selected position of the filter disk is empty, enter three “...”.
Press Enter to complete the field entry. The system will return to the previous Edit
Menu screen.
Calendar Setting
Move the cursor to the desirable position for date or time input by using the Up,
Down, and Right arrow keys. Enter the present date or time using the number keys.
Press Enter to complete the field entry. The system will return to the previous Edit
Menu screen.
Lab. Name Setting
Use the Up and Down arrow keys to select from “A” to “Z” and symbols.
Use the Number keys for numeric input.
Use the Right arrow key to move the cursor to the right.
Use the Left arrow key to return the cursor to the Edit Menu screen.
Pressing the ./FUNC” key will toggle the character mode between Upper case
alphabet, Lower case alphabet, and symbol. The current character mode is indicated on
the lower right corner of the LCD.
Save STD Curve
> Save STD Curve
Rename STD Curve
Save STDC
Save STDC Setting
Select “Save STDC” in Edit Menu screen above, and press Enter. The Save STD
Curve Menu appears on the screen.
Move the cursor to the desired position by using the Up and Down arrow keys.
Select STD storage #
> 1:12/03/04 15:00
2:******** *****
3:15/03/04 10:30
Select for renaming
> 1:16/03/04 11:25
2:****** *****
3:15/03/04 10:30
Save STD Curve
To save a STD Curve, select the storage number between 1 and 5. Use the Up and
Down arrow keys to move the cursor to the desired storage number, and press
Enter to complete the selection.
After the storage number selection, the ”
Are you sure? ” message appears.
Select “Yes” or “No” and press Enter. In case of “Yes”, the reader saves the STD
Curve and returns to the Edit Menu screen.
If the curve fit calculation is not done, or has not finished successfully, an error
message will appear and the STD Curve will not be saved.
STD curve does not
exist yet.
Press any key
Save STD Curve:
#1:16/03/04 11:25
Are you sure?
> Yes No
Rename STD Curve
To change a name of an STD Curve, select a storage number between 1 and 5.
Use the Up and Down arrow keys to move the cursor to the desired storage
number, and press Enter to complete the selection.
Use the Up and Down arrow keys to select from “A” to “Z” and symbol.
Use the Number keys for numeric input.
Use the Right arrow key to move the cursor to the right.
Use the Left arrow key to return the cursor to the Edit Menu screen.
Pressing the ./FUNC” key will toggle the character mode between Upper case
alphabet, Lower case alphabet, and symbol. The current character mode is
indicated on the lower right corner of the LCD.
#1:16/03/04 11:25
>STD Curve #1 <
[ABC]
Save STD Curve
Rename STD Curve
