background image

A-10

BROADway - Release 4.00

Ports and Cables

NHP160 Connector Pinouts

59

gray/purple

T1E1_TxRNG8

60

blue/white band

T1E1_TxRNG1

61

orange/white band

T1E1_RxRNG1

62

green/white band

T1E1_RxRNG0

63

brown/white band

T1E1_TxRNG0

64

gray/white band

T1E1_TxRNG3

65

blue/red band

T1E1_RxRNG3

66

orange/red band

T1E1_RxRNG2

67

green/red band

T1E1_TxRNG2

68

brown/red band

NO CONNECT

SCSI Pin

Color

Signal
