Carrier Access BROADway System 770-0125-AB - Manual (Page 72)

3-24 BROADway - Release 4.00
Configuration
Managing the BROADway Configuration Database
Managing the Database Using the GUI
To modify the configuration database
status using the GUI interface:
1. In the menu bar, click Admin, then
Database.
2. The Database Management
window will appear. Review
which databases are currently in
the RUNNING, SAVED, and
OFFLINE states.
NOTE: To change the currently
RUNNING database to a
previously stored configuration,
you must reboot the BROADway
system. You cannot move a
database directly into the Running
folder. You can only move a
database into the Saved folder.
When you reboot the BROADway
system, the database in the Saved
folder becomes the RUNNING
database.
3. To select the current RUNNING database or an OFFLINE database as the SAVED database:
- Select the database that you want to move to SAVED. Click Copy .
- In the To field, select Saved.
- If you want to change the name of the
database (from that shown in the From
field), type a new name in the box under
the Saved field.
- Click OK.
NOTE: Database names are limited to 19
characters and must not begin with a numeric
character.
