BROADway - Release 4.00 2-25
Installation
Installing OSP155/ESP155/BCP155 Line Interface Cards
Cabling the OSP155 and BCP155
OSP155 and BCP155 cables should be attached to the line interface card before installing in the
BROADway chassis. Be careful when installing OSP155 or BCP155 cards; minimize the potential for
eye damage by not looking directly into any fiber optic cable or optical transceiver port when the card
is inserted into a powered system. To cable and insert the OSP155 and BCP155 cards:
1. First attach the duplex fiber optic cable to the line interface port:
Singlemode Fiber Optic Cable
Be careful not to bend the cable too sharply,
or you might break the fiber inside
Remove the dust plugs from the optical transceiver
Insert the singlemode fiber optic cable
