A-8 BROADway - Release 4.00
Ports and Cables
NHP160 Connector Pinouts
NHP160 Connector Pinouts
There are several cables you can use to connect the NHP160 cards. These are the pinouts for the un-
terminated SCSI cable (at any length).
SCSI Pin Color Signal
1 white/blue T1E1_RxTIP15
2 white/orange T1E1_TxTIP15
3 white/green T1E1_TxTIP14
4 white/brown T1E1_RxTIP14
5 white/gray T1E1_RxTIP13
6 red/blue T1E1_TxTIP13
7 red/orange T1E1_TxTIP12
8 red/green T1E1_RxTIP12
9 red/brown T1E1_TxTIP7
10 red/gray T1E1_RxTIP7
11 black/blue T1E1_TxTIP11
12 black/orange T1E1_RxTIP11
13 black/green T1E1_TxTIP10
14 black/brown T1E1_RxTIP10
15 black/gray T1E1_TxTIP6
16 yellow/blue T1E1_RxTIP6
17 yellow/orange NO CONNECT
18 yellow/green T1E1_TxTIP5
19 yellow/brown T1E1_RxTIP5
20 yellow/gray T1E1_TxTIP4
21 purple/blue T1E1_RxTIP4
22 purple/orange T1E1_TxTIP9
23 purple/green T1E1_RxTIP9
24 purple/brown T1E1_RxTIP8
25 purple/gray T1E1_TxTIP8
26 white/blue band T1E1_TxTIP1
27 white/orange band T1E1_RxTIP1
