3-30 BROADway - Release 4.00
Configuration
Upgrading System Software
3. Use an FTP client program to open an FTP session to the BROADway node and upload the
system software file to the /FLASH folder. This example shows the standard Microsoft
Windows FTP client. The upload time might be more than several minutes if the IP connection
to the BROADway node is over a low-speed WAN link:
c:\>ftp 192.168.5.60
Connected to 192.168.5.60.
220 VxWorks (5.4.2) FTP server ready
User (192.168.5.60:(none)): ADMIN
331 Password required
Password:
230 User logged in
ftp> cd /FLASH
250 Changed directory to "/FLASH"
ftp> bin
200 Type set to I, binary mode
ftp> put c:\temp\bw308.zip
200 Port set okay
150 Opening BINARY mode data connection
226 Transfer complete
ftp: 4664234 bytes sent in 124.73Seconds 37.40Kbytes/sec.
ftp> bye
221 Bye...see you later
