Preface
Compliance
FCC Requirements, Part 68
The following instructions are provided to ensure compliance with the Federal Communications
Commission (FCC) Rules, Part 68.
1. This equipment complies with Part 68 of the FCC rules. This unit bears a label which contains
the FCC registration number. If requested, this information must be provided to the telephone
company.
2. This equipment uses the following standard jack types for network connection:
3. This equipment is designed to be connected to the telephone network or premises wiring using
cabling that complies with the requirements of FCC Part 68 rules.
4. In the unlikely event that this equipment causes harm to the telephone network, the telephone
company can temporarily disconnect your service. The telephone company will try to warn you
in advance of any such disconnection, but if advance notice isn't practical, it may disconnect
the service first and notify you as soon as possible afterwards. In the event such a disconnection
is deemed necessary, you will be advised of your right to file a complaint with the FCC.
5. From time to time, the telephone company may make changes in its facilities, equipment, or
operations which could affect the operation of this equipment. If this occurs, the telephone
company is required to provide you with advance notice so you can make the modifications
necessary to maintain uninterrupted service.
6. Repair service and warranty information can be obtained from:
Carrier Access Corporation
5395 Pearl Parkway
Boulder, CO 80301-2490
(800) 786-9929 or (303) 442-5455
7. All repairs should be performed by Carrier Access or an authorized agent. It is the responsibility
of the users requiring service to report the need for service to Carrier Access or an authorized
agent.
Card
Type Service
Type Framing Coding REN/
SOC FIC Network
Jack
NHP160 1.544 Mbps D4 (superframe) AMI 6.0N 04DU9-BN Hardwired
1.544 Mbps D4 (superframe) B8ZS 6.0N 04DU9-DN Hardwired
1.544 Mbps ESF (extended
superframe) AMI 6.0N 04DU9-1KN Hardwired
1.544 Mbps ESF (extended
superframe) B8ZS 6.0N 04DU9-1SN Hardwired
NIP400 1.544 Mbps D4 (superframe) AMI 6.0N 04DU9-BN Hardwired
1.544 Mbps D4 (superframe) B8ZS 6.0N 04DU9-DN Hardwired
1.544 Mbps ESF (extended
superframe) AMI 6.0N 04DU9-1KN Hardwired
1.544 Mbps ESF (extended
superframe) B8ZS 6.0N 04DU9-1SN Hardwired
