BROADway - Release 4.00 A-9
Ports and Cables
NHP160 Connector Pinouts
28 white/green band T1E1_RxTIP0
29 white/brown band T1E1_TxTIP0
30 white/gray band T1E1_TxTIP3
31 red/blue band T1E1_RxTIP3
32 red/orange band T1E1_RxTIP2
33 red/green band T1E1_TxTIP2
34 red/brown band NO CONNECT
35 blue/white T1E1_RxRNG15
36 orange/white T1E1_TxRNG15
37 green/white T1E1_TxRNG14
38 brown/white T1E1_RxRNG14
39 gray/white T1E1_RxRNG13
40 blue/red T1E1_TxRNG13
41 orange/red T1E1_TxRNG12
42 green/red T1E1_RxRNG12
43 brown/red T1E1_TxRNG7
44 gray/red T1E1_RxRNG7
45 blue/black T1E1_TxRNG11
46 orange/black T1E1_RxRNG11
47 green/black T1E1_TxRNG10
48 brown/black T1E1_RxRNG10
49 gray/black T1E1_TxRNG6
50 blue/yellow T1E1_RxRNG6
51 orange/yellow NO CONNECT
52 green/yellow T1E1_TxRNG5
53 brown/yellow T1E1_RxRNG5
54 gray/yellow T1E1_TxRNG4
55 blue/purple T1E1_RxRNG4
56 orange/purple T1E1_TxRNG9
57 green/purple T1E1_RxRNG9
58 brown/purple T1E1_RxRNG8
SCSI Pin Color Signal
