3-12 BROADway - Release 4.00
Configuration
Logging In With the Web Browser Interface (GUI)
8. The browser window will change to reflect the BROADway configuration applet loader, and
then you will be presented with the BROADway applet window as shown in the following
figure.
The BROADway applet window will show the name BROADway and then the system node name will
be shown in parentheses. If you have not yet assigned a system node name or you kept the default
system node name BROADway, the system IP address will be displayed.
You must leave the main browser window running in the background while the applet is operational.
You can, however, minimize the window. Closing the main browser window will log you out and
disconnect you from the BROADway system. You will have to log back in and restart the applet to
continue managing the system.
NOTE: Up to three GUI sessions can be running on any single BROADway system. If a
fourth client session attempts to connect to the system, the login will not complete and you
will be presented with an error message.
To log out, click the Close button on the main browser window. If you accidentally close the applet
window and the browser window is still open or minimized, you should close this window and restart
the browser to log back into the BROADway system. Even though use of the Refresh button will appear
to open up a new GUI window, problems can occur later on during the same session.
Click here to minimize this window
This window must remain running in the background
Node Name
Click here to close the window and log off
or
IP address
