System | Image Lab Software Overview
26
Software Overview
The following illustration shows the Image Lab main window. The paragraphs
below describe the major software elements.
Main Window
There is one main window used in Image Lab. Results Files, protocols, and
dialog boxes presenting choices all open on the Desktop.
Quick Start
The Quick Start guides users through creating, opening,
and viewing protocols and results. It also allows one-
button operation for running a default protocol.
Toolbar
Analysis
Quick Start
Desktop
Status Bar
Menu
Items
Tool Box
