Operating Instructions 67
04/04/2011 166-207M
Refer to Figure 73
10. Open (front) Calibration door
. A small amount of
seed may fall into auger inlet hopper.
Do not open (rear) Clean-Out Door before auger
is operating, or material may flow in large volume
and overflow auger inlet hopper.
11. Check that auger controls are at center/off.
Null4:
Refer to Figure 75
12. At Fan/Auger selector valve, select AUGER.
Null4:
13. Activate fan/auger hydraulic circuit. The auger does
not operate at this time.
Rotating Auger Hazard:
Use two people for the next steps, to avoid requiring a single
person to be alone and in close proximity to a rotating auger.
Null4:
Figure 74
Open Calibration Door
26401
2
1
1
2
Null4:
Figure 75
Fan/Auger Selector Valve
29525
Null4:
Auger Unload: Hydraulic Circuit Operation
Lift
Fan,
Auger
Fold, Tilt,
Marker
Transport
Hooks
Neutral Extend Neutral Neutral
