Appendix A - Reference Information 153
04/04/2011 166-207M
Monitor Setup Data
Seed monitor setup is normally performed using the
Quick Start Guide (QSG, part number 110011516). If the
QSG is not available, the table at right, plus the Specifi-
cations and Capacities data starting on page 144, pro-
vide the required and key factory default settings.
Notes:
MetaData: End of Seed Hose Port Maps
a Required Value:
Do not change.
b Factory Default:
An approximate initial value. Refine with material
data and/or calibration.
c Type:
Change to “GRAN...CONTROL” if optional variable
rate seeding is installed.
Note NTA907HD NTA3007HD
Row Setup
Model: NTA..-3610 a 9 sensors/WSMB
Model: NTA..-4875 a 12 sensors/WSMB
Model: NTA..-6006 a 15 sensors/WSMB
Ground Speed
Source a Digital Frequency
Constant b 38416 46837
Alarm Delay (generally) b 5 sec
Accessory Setup
Hopper Level Logic a ACTIVE LO
Front Hopper is no. a 1
# of RPM sensors a 1
Fan RPM Constant a 3 pulses/rev
RPM filter a 50 %
# of Pressure Sensors a 2
High Alarm b 8.6 kpa 20 oz/in3
Low Alarm b 1.7 kpa 4 oz/in3
Pressure Filter a 50
Material Setup
Type (for seeding) c GRAN SEED MONITOR
Type (for fertilizer) c GRAN FERT MONITOR
Total # of Towers a 4
Material Defaults
Seed b 0.77 kg/l 60 lbs/bu
Fertilizer b 0.96 kg/l 60 lbs/ft3
Calibration Constants
Seeding b 3031 85831
Fertilizer b 2931 82996
Channel Setup
Input Filter a 50%
Sensor Constant a 360 pulses/rev
Gear Ratio a 1
