Great Plains NTA3007HD Operator Manual - Manual (Page 155)

Appendix A - Reference Information 151
04/04/2011 166-207M
60-Row Port Map, Left
NTA907HD-6006 and NTA3007HD-6006 Port Map
P01
P02
P03
P04 P05
P06
P07
P08
P09
P10
P11
P12 P13
P14
P15
T1
R01
R02
R04
R06 R08
R10
R12
R14
R15
R13
R11
R09
R07
R05
R03
P01
P02
P03
P04
P05
P06
P07
P08 P09
P10
P11
P12
P13
P14
P15
T2
R22
R16
R17
R18
R19
R20
R21
R30 R29
R28
R27
R26
R25
R24
R23
U
F
B
L R
U
Drill Meter Tower Tower Row Hose Length WSMB
Section Outlet Number Port Unit Inches Metric Input
Left Wing M2 T1 P01 R01 W1-01
Left Wing M2 T1 P02 R02 W1-02
Left Wing M2 T1 P15 R03 W1-03
Left Wing M2 T1 P03 R04 W1-04
Left Wing M2 T1 P14 R05 W1-05
Left Wing M2 T1 P04 R06 W1-06
Left Wing M2 T1 P13 R07 W1-07
Left Wing M2 T1 P05 R08 W1-08
Left Wing M2 T1 P12 R09 W1-09
Left Wing M2 T1 P06 R10 W1-10
Left Wing M2 T1 P11 R11 W1-11
Left Wing M2 T1 P07 R12 W1-12
Left Wing M2 T1 P10 R13 W1-13
Left Wing M2 T1 P08 R14 W1-14
Left Wing M2 T1 P09 R15 W1-15
Left Wing M3 T2 P02 R16 W2-01
Left Wing M3 T2 P03 R17 W2-02
Left Wing M3 T2 P04 R18 W2-03
Left Wing M3 T2 P05 R19 W2-04
Left Wing M3 T2 P06 R20 W2-05
Left Wing M3 T2 P07 R21 W2-06
Center M3 T2 P01 R22 W2-07
Center M3 T2 P15 R23 W2-08
Center M3 T2 P14 R24 W2-09
Center M3 T2 P13 R25 W2-10
Center M3 T2 P12 R26 W2-11
Center M3 T2 P11 R27 W2-12
Center M3 T2 P10 R28 W2-13
Center M3 T2 P09 R29 W2-14
Center M3 T2 P08 R30 W2-15
