NTA-3510 Port Assignments, 7.5in (25.4cm) Drill
Drill Model: NTA3510-5575
Towers are numbered from drill left (Tower 1).
Harness connectors are numbered on the cable: “Row 1”
through “Row 12”. Lead “ROW 12” is unused (n/c).
Tower Ports are numbered Clockwise from mount center
(Port 1) to Port 11.
Openers are numbered from drill left (Row 1).
Tower
Harness
Port
Opener
Tower
Harness
Port
Opener
Tower 1
ROW 10
Port 1
10
Tower 4
ROW 5
Port 1
38
ROW 4
Port 2
4
ROW 4
Port 2
37
ROW 2
Port 3
2
ROW 3
Port 3
36
ROW 1
Port 4
1
ROW 2
Port 4
35
ROW 3
Port 5
3
ROW 1
Port 5
34
ROW 5
Port 6
5
ROW 7
Port 6
40
ROW 6
Port 7
6
ROW 10
Port 7
43
ROW 7
Port 8
7
ROW 9
Port 8
42
ROW 8
Port 9
8
ROW 11
Port 9
44
ROW 9
Port 10
9
ROW 8
Port 10
41
ROW 11
Port 11
11
ROW 6
Port 11
39
ROW 12
n/c
-
ROW 12
n/c
-
Tower 2
ROW 7
Port 1
18
Tower 5
ROW 6
Port 1
50
ROW 6
Port 2
17
ROW 4
Port 2
48
ROW 5
Port 3
16
ROW 2
Port 3
46
ROW 3
Port 4
14
ROW 1
Port 4
45
ROW 1
Port 5
12
ROW 3
Port 5
47
ROW 2
Port 6
13
ROW 5
Port 6
49
ROW 4
Port 7
15
ROW 7
Port 7
51
ROW 8
Port 8
19
ROW 9
Port 8
53
ROW 10
Port 9
21
ROW 11
Port 9
55
ROW 11
Port 10
22
ROW 10
Port 10
54
ROW 9
Port 11
20
ROW 8
Port 11
52
ROW 12
n/c
-
ROW 12
n/c
-
Tower 3
ROW 10
Port 1
32
ROW 8
Port 2
30
ROW 6
Port 3
28
ROW 2
Port 4
24
ROW 1
Port 5
23
ROW 3
Port 6
25
ROW 4
Port 7
26
ROW 5
Port 8
27
ROW 7
Port 9
29
ROW 9
Port 10
31
ROW 11
Port 11
33
ROW 12
n/c
-
