NTA-3510 Port Assignments, 10in (25.4cm) Drill
Drill Model: NTA3510-4010
Towers are numbered from drill left (Tower 1).
Harness connectors are numbered on the cable: “Row 1”
through “Row 12” (some are not connected [n/c]).
Tower Ports are numbered Clockwise from mount center
(Port 1) to Port 8.
Openers are numbered from drill left (Row 1).
Tower
Harness
Port
Opener
Tower
Harness
Port
Opener
Tower 1
ROW 8
Port 1
8
Tower 4
ROW 2
Port 1
26
ROW 3
Port 2
3
ROW 1
Port 2
25
ROW 1
Port 3
1
ROW 4
Port 3
28
ROW 2
Port 4
2
ROW 5
Port 4
29
ROW 4
Port 5
4
ROW 6
Port 5
30
ROW 5
Port 6
5
ROW 7
Port 6
31
ROW 6
Port 7
6
ROW 8
Port 7
32
ROW 7
Port 8
7
ROW 3
Port 8
27
ROW 9-12
n/c
-
ROW 9-12
n/c
-
Tower 2
ROW 7
Port 1
15
Tower 5
ROW 6
Port 1
38
ROW 6
Port 2
14
ROW 1
Port 2
33
ROW 1
Port 3
9
ROW 2
Port 3
34
ROW 2
Port 4
10
ROW 3
Port 4
35
ROW 3
Port 5
11
ROW 4
Port 5
36
ROW 4
Port 6
12
ROW 5
Port 6
37
ROW 5
Port 7
13
ROW 7
Port 7
39
ROW 8
Port 8
16
ROW 8
Port 8
40
ROW 9-12
n/c
-
ROW 9-12
n/c
-
Tower 3
ROW 7
Port 1
23
ROW 8
Port 2
24
ROW 5
Port 3
21
ROW 3
Port 4
19
ROW 1
Port 5
17
ROW 2
Port 6
18
ROW 4
Port 7
20
ROW 6
Port 8
22
ROW 9-12
n/c
-
