3N4010HDA Port Assignments, 10in (25.4cm) Drill
Drill Model: 3N-4010HDA-4810
Towers are numbered from drill left (Tower 1).
Harness connectors are numbered on the cable: “Row 1”
through “Row 12” (some are not connected [n/c]).
Tower Ports are numbered Clockwise from mount center
(Port 1) to Port 8.
Openers are numbered from drill left (Row 1).
Tower
Harness
Port
Opener
Tower
Harness
Port
Opener
Tower 1
ROW 3
Port 1
3
Tower 4
ROW 2
Port 1
26
ROW 1
Port 2
1
ROW 4
Port 2
28
ROW 2
Port 3
2
ROW 6
Port 3
30
ROW 4
Port 4
4
ROW 8
Port 4
32
ROW 6
Port 5
6
ROW 7
Port 5
31
ROW 8
Port 6
8
ROW 5
Port 6
29
ROW 7
Port 7
7
ROW 3
Port 7
27
ROW 5
Port 8
5
ROW 1
Port 8
25
ROW 9-12
n/c
-
ROW 9-12
n/c
-
Tower 2
ROW 3
Port 1
11
Tower 5
ROW 5
Port 1
37
ROW 1
Port 2
9
ROW 3
Port 2
35
ROW 2
Port 3
10
ROW 1
Port 3
33
ROW 4
Port 4
12
ROW 2
Port 4
34
ROW 6
Port 5
14
ROW 4
Port 5
36
ROW 8
Port 6
16
ROW 6
Port 6
38
ROW 7
Port 7
15
ROW 8
Port 7
40
ROW 5
Port 8
13
ROW 7
Port 8
39
ROW 9-12
n/c
-
ROW 9-12
n/c
-
Tower 3
ROW 7
Port 1
23
Tower 6
ROW 3
Port 1
43
ROW 5
Port 2
21
ROW 1
Port 2
41
ROW 3
Port 3
19
ROW 2
Port 3
42
ROW 1
Port 4
17
ROW 4
Port 4
44
ROW 2
Port 5
18
ROW 6
Port 5
46
ROW 4
Port 6
20
ROW 8
Port 6
48
ROW 6
Port 7
22
ROW 7
Port 7
47
ROW 8
Port 8
24
ROW 5
Port 8
45
ROW 9-12
n/c
ROW 9-12
n/c
