Great Plains Mfg., Inc.
36
Blockage Monitor Kits
168-414M
10/29/2008
NTA-3010 Port Assignments, 10in (25.4cm) Drill
Drill Model: NTA3010-3610
Towers are numbered from drill left (Tower 1).
Harness connectors are numbered on the cable: “Row 1”
through “Row 12” (some are not connected [n/c]).
Tower Ports are numbered Clockwise from mount center
(Port 1) to Port 9.
Openers are numbered from drill left (Row 1).
Tower
Harness
Port
Opener
Tower
Harness
Port
Opener
Tower 1
ROW 5
Port 1
5
Tower 3
ROW 5
Port 1
23
ROW 3
Port 2
3
ROW 3
Port 2
21
ROW 1
Port 3
1
ROW 1
Port 3
19
ROW 2
Port 4
2
ROW 2
Port 4
20
ROW 4
Port 5
4
ROW 4
Port 5
22
ROW 6
Port 6
6
ROW 6
Port 6
24
ROW 8
Port 7
8
ROW 7
Port 7
25
ROW 9
Port 8
9
ROW 9
Port 8
27
ROW 7
Port 9
7
ROW 8
Port 9
26
ROW 10-12
n/c
-
ROW 10-12
n/c
-
Tower 2
ROW 5
Port 1
14
Tower 4
ROW 6
Port 1
33
ROW 4
Port 2
13
ROW 4
Port 2
31
ROW 2
Port 3
11
ROW 2
Port 3
29
ROW 1
Port 4
10
ROW 1
Port 4
28
ROW 3
Port 5
12
ROW 3
Port 5
30
ROW 6
Port 6
15
ROW 5
Port 6
32
ROW 7
Port 7
16
ROW 7
Port 7
34
ROW 9
Port 8
18
ROW 9
Port 8
36
ROW 8
Port 9
17
ROW 8
Port 9
35
ROW 10-12
n/c
-
ROW 10-12
n/c
-
