Great Plains Mfg., Inc.
Installation Instructions
33
10/29/2008
168-414M
CTA4000/HD Port Assignments, 10in (25.4cm) Drill
Drill Model: CTA4000-5010, CTA4000HD-5010
Towers are numbered from drill left (Tower 1).
Harness connectors are numbered on the cable: “Row 1”
through “Row 12” (some are not connected [n/c]).
Tower Ports are numbered Clockwise from mount center
(Port 1) to Port 10.
Openers are numbered from drill left (Row 1).
Tower
Harness
Port
Opener
Tower
Harness
Port
Opener
Tower 1
ROW 7
Port 1
7
Tower 4
ROW 1
Port 1
31
ROW 9
Port 2
9
ROW 2
Port 2
32
ROW 10
Port 3
10
ROW 5
Port 3
35
ROW 8
Port 4
8
ROW 7
Port 4
37
ROW 6
Port 5
6
ROW 9
Port 5
39
ROW 4
Port 6
4
ROW 10
Port 6
40
ROW 2
Port 7
2
ROW 8
Port 7
38
ROW 1
Port 8
1
ROW 6
Port 8
36
ROW 3
Port 9
3
ROW 4
Port 9
34
ROW 5
Port 10
5
ROW 2
Port 10
32
ROW 11-12
n/c
-
ROW 11-12
n/c
-
Tower 2
ROW 10
Port 1
20
Tower 5
ROW 5
Port 1
45
ROW 8
Port 2
18
ROW 7
Port 2
47
ROW 6
Port 3
16
ROW 9
Port 3
49
ROW 4
Port 4
14
ROW 10
Port 4
50
ROW 2
Port 5
12
ROW 8
Port 5
48
ROW 1
Port 6
11
ROW 6
Port 6
46
ROW 3
Port 7
13
ROW 4
Port 7
44
ROW 5
Port 8
15
ROW 2
Port 8
42
ROW 7
Port 9
17
ROW 1
Port 9
41
ROW 9
Port 10
19
ROW 3
Port 10
43
ROW 11-12
n/c
-
ROW 11-12
n/c
-
Tower 3
ROW 4
Port 1
24
ROW 2
Port 2
22
ROW 1
Port 3
21
ROW 3
Port 4
23
ROW 5
Port 5
25
ROW 7
Port 6
27
ROW 9
Port 7
29
ROW 10
Port 8
30
ROW 8
Port 9
28
ROW 6
Port 10
26
ROW 11-12
n/c
-
