Page 119
Great Plains Manufacturing, Inc.
Appendix A - Reference Information
115
2012-12-27
401-832M
Chain Routing
Wing Ground Drive Chains
Figure 116
Wing Ground Drive Chain Routing
34446
Range Sprockets:
20T, 30T, 30T
Transmission Sprockets:
17T, 19T, 23T, 23T, 24T,
25T, 26T, 27T, 28T
A
B
C
D
19T
30T
18T
104P
76P
52P
49P
C
A
A
19T
19T
20T
D
122P
