Using Master Code 4732 and above information, the lock would be programmed as follows:
99# 4732* 50# 1# 05# 875* 875* 3# 12# 2226* 2226* 2# 08# 5444* 5444* 1# 50# 3367* 3367*
If all user codes are type 1, it is not necessary to enter the type number with each entry.
The format now simplifies to:
99# Master or Supervisor Code* User Number a# User code a* User Code a* UNb# UCb* UCb* UNc# UCc*
UCc*....... UN_# UC_* UC_**
An example with three user codes is shown below:
Using Master Code 45988 and above information, the lock would be programmed as follows:
99# 45988* 07# 77* 77* 15# 67832* 67832* 91# 7568* 7568**
To chain the User Number delete procedure:
99# Master Code* User Number a#** UNb#** UNc#**....... UN_#****
Using the information from the above example:
99# 45988* 07#** 15#** 91#****
Type User Number User Code
1 07 77
1 15 67832
1 91 7568
Lock Response: Audible beep
When programming multiple User Numbers and Codes into the G1.5 Dorm Lock with keypad, it is not necessary to
leave and re-enter the programming Mode (50) for each entry. Multiple entries may be chained together and the
three different types of user codes (Standard, Passage and One Time) may be mixed.
The format to be used is as follows:
“T” is the Type of user code with “1” Standard, “2” Passage and “3” One Time.
“UN_” is User Number (04-99)
“UC_” is User Code (2 to 6 digits) which correlates with the User Number
99# Master or Supervisor Code* 50# Type# User Number a# User Code a*
User Code a* T# UNb# UCb* UCb* T# UNc# UCc* UCc* ...... T# UN_# UC_* UC_**
An example with four user codes is shown below:
Type User Number User Code
1 05 875
3 12 2226
2 08 5444
1 50 3367
- +
- +
-
+
-
+
+
-
+
- G1.5 - PA
Comm Enable
Push Button
Chain Programming
Label indicates version
of electronics
Keypad Programming Instructions
18
