Profile Series v.G1.5 Mortise Dorm Lock
4. Install battery keeper clip by
inserting tabs into bottom slots.
To remove keeper, pull on top
tab (Fig. 3).
5. Attach battery cover to inside
escutcheon making sure to line
up tabs with retaining slots in
battery cover. Secure with
security screw (Ref. Fig. 4).
--
+ +
--
+ +
--
+ +
--
+ +
+ +
--
+ +
--
Security
screw
Security tool
01-0297 included
Outside of
door
•
Front plate
(2) Flat head screws
3. Place (6) “AA” batteries into the
compartment being careful to
align polarity properly (Ref. Fig. 2).
Inside of
door
Battery
cover
Battery
keeper
Lockbody screws
- Polarity
+ Polarity
Bottom
slots
Top tab
Tabs
Retaining
slots
6.11 – Battery Installation/Attaching Outside Front
1. Tighten lockbody screws (Ref. Fig. 1)
2. Attach front plate with (2) flat head screws
Fig. 1
Fig. 4
13
© SARGENT Manufacturing Company 2006, 2007
For installation assistance, contact SARGENT at 800-810-WIRE (9473)
Fig. 3 Fig. 2
