SARGENT GX Series (3 Line) User Manual

Door template, A7591a

background image

INSTALLATION INSTRUCTIONS FOR
GX SERIES LEVER LOCK 3U93 FUNCTION DUMMY TRIM

FOR INSTALLATION ASSISTANCE CALL SARGENT AT 1-800-727-5477 • www.sargentlock.com

Drill
1/8" (3mm) drill bit
Phillips screwdriver
Flat Screwdriver

HERRAMIENTAS UTILZADAS PARA LA
INSTALACION DE SU CERRADURA
Taladro
Broca de 1/8” (3mm)
Desarmador Phillips
Desarmador plano

INSTALLATION INSTRUCTIONS
Mount lock after door is painted

(

)

(

)

CAUTION: Avoid the use of

solvents, gasoline, detergents and

other substances when cleaning
your lock as these products may

damage its appearance.

PRECAUCION: Evite el uso de

solventes, gasolina, detergentes y

otras sustancias para la limpieza de su

cerradura, ya que dañarán la

apariencia de esta. Limpie únicamente

con un paño húmedo.

DRILL THREE HOLES

1/8" (3 mm) IN DIAMETER

AND 3/8" (8 mm.) IN

DEPTH (APPROX.)

HACER TRES PERFORACIONES

DE 1/8" (3 mm) DE DIAMETRO Y

3/8" (9 mm) DE PROFUNDIDAD

APROXIMADAMENTE.

ANTES DE

RECORTAR LEA

LAS INSTRUCCIONES

TEMPLATE TO INSTALL

DUMMY LEVER LOCK

PLANTILLA PARA INSTALAR

CERRADURA DUMMY MANIJA

CORTE A LO LARGO DE LA LINEA

CUT ALONG THESE LINES

DOBLE AQUI SOBRE EL

CANTO DE LA PUERTA

INSTRUCTIVO DE INSTALACION PARA CERRADURA DUMMY DE MANIJA
Colocar la cerradura una vez pintada la puerta

TOOLS REQUIRED FOR THE LOCK INSTALLATION

A7591A

DOOR TEMPLATE

(3) 1/8" (3mm) HOLES
SELECT ACCORDING TO DESIRED
BACKSET
