SERVICE 4 - 10 Manual 0-2529
10. Position the nylon outer sleeving over the shielded
inner sleeving. The shielded inner sleeving must be
completely covered by the outer sleeving to avoid any
possible contact with the mounting assembly.
11. Secure the nylon outer leads sleeving to the leads with
electrical tape. Position the tape close to the back of the
mounting assembly.
Refer to Figure 4-E (page 4-7) and:
12. Open the leads connection access door on the power
supply. Remove the hose clamp that secures the
shielded inner leads sleeving to the brass grounding
tube.
13. Disconnect the plasma, secondary, coolant supply and
coolant return leads from the bulkhead.
14. Position the replacement leads and connect the plasma,
secondary, coolant supply and coolant return leads to
the bulkhead.
15. Attach the shielded inner leads sleeving to the brass
grounding tube and secure with hose clamp. The
shielded inner sleeving must not contact any torch
fittings, ferrules, or connections.
Machine Torch Leads
Replacement (continued)
Power Supply Connections
