Manual 0-2529 1 - 3 INTRODUCTION & DESCRIPTION
1.3 TORCH SPECIFICATIONS
• PCH-150 90° Hand Torch
• PCH-150 70° Hand Torch
• PCM-150 Machine Torch
Standard lengths of 25 ft (7.6 m) or 50 ft (15.2 m).
Extendable in increments of 25 ft or 50 ft up to a maximum
of 150 ft (45.7 m) with available leads extension packages
(see Options and Accessories, page 1-5)
150 Amps Maximum, Direct Current Straight Polarity
Hand and Machine Torch rated at 100% Duty Cycle
Most materials up to 2.0 in (50.8 mm)
Torch Configurations
Torch Leads Lengths
Cutting Range
Current Rating
Plasma
Secon-
dary
Gases
• Compressed Air
• Oxygen (O
2
)
• Argon/Hydrogen
(Ar/H 2 )
• Nitrogen (N
2
)
• Compressed Air
• Nitrogen (N
2 )
• Carbon Dioxide
(CO
2
)
• Water
Hot Flow *
For Cutting:
22-28 scfh
(10.4-13.2 lpm)
For Gouging:
22-43 scfh
(10.4-20.3 lpm)
For Cutting or
Gouging:
220 scfh
(103 lpm)
8 gph
(30.3 lph)
Pressure
50 psi
(3.4 bar)
50 psi
(3.4 bar)
Min.50 psi
(3.4 bar)
Gas Requirements
* Hot flow is measured with the main arc activated. When
pressure is set correctly the plasma gas flow rate is
significantly higher until the arc is initiated.
PCH-150 90° Hand Torch (without Leads) - 1.0 lb (.45 kg) Weight
NOTE
