PARTS LIST 5 - 12 Manual 0-2529
5.8 MAIN HEATSINK COMPONENTS
Item Qty. Catalog Description Reference
No. Number Designator
1 1 9-1404 Main Heatsink
2 4 9-1303 Capacitor - 550 mfd, 400VDC C7-10
3 1 8-4521 Capacitor/Heatsink Bracket
4 1 8-2176 Air Foil Support
5 2 9-4212 Capacitor Clamp
6 1 9-6663 Heatsink Support Assembly
7 1 9-1406 Thermstrate Pad
8 1 IGBT (See Note) Q1
9 2 9-1305 Capacitor - 10 mfd, 400V Hi-Current C11,12
10 1 8-6314 Capacitor Mounting Bracket
11 1 8-1168 70 Amp STR Diode Replacement Kit Includes: D7-10, D11-14
1 Diode, 70A, 600V STR Fast
1 Thermal Interface Pad 0.75 Dia
12 2 9-1408 Capacitor - .15 mfd, 630V C13,14
13 1 9-1409 Suppression Coil Assembly L1
14 1 8-6316 Diode Lead Bracket
15 1 9-1410 Heatsink Suppression PC Board Assembly
16 1 8-6315 Capacitor Bracket/PC Board Support
17 3 9-1405 Resistor - 100 ohm, 100W R2,3,18
18 2 8-6677 Resistor - 3k ohm, 100W R1,12
19 1 9-2731 Relay Socket
20 1 9-5256 Relay - DPDT, 110 VDC PSR
21 1 8-6675 Negative Diode Plate
22 1 8-6674 Positive Diode Plate
23 1 8-6155 Diode Suppression PC Board Assembly
24 1 8-6153 150 Amp REV Diode Replacement Kit Includes: D1,3,5
1 Diode, 150 Amp, 800V, REV
Thermal Interface PAd 1.06 Dia
25 1 8-6152 150 Amp STR Diode Replacement Kit Includes: D2,4,6
1 Diode, 150 Amp, 800V, STR
Thermal Interface PAd 1.06 Dia
26 1 8-4523 PTC Resistor Assembly TS3
27 1 9-4297 Relay Hold-Down Spring
28 1 8-6676 Transistor/Coil Bracket
29 1 Transistor Harness Assembly (See Note)
30 1 8-5147 Standoff
31 10 8-6678 Fiber Washer
32 1 9-4392 Shunt
33 1 9-4391 Shunt Amp PC Board
NOTE
This part is included in Kit No. 7-3360.
All parts in the kit must be replaced at the
same time. Failure to replace all parts to-
gether will result in component failure.
