tekmar 369 Zone Control Installation - Manual (Page 22)

Copyright © D 369 -10/00 22 of 32
If the 7DAY/24h item is set to 7DAY, the schedule listed below for SATURDAY is also available for SUNDAY, MONDAY, TUESDAY,
WEDNESDAY, THURSDAY and FRIDAY.
369 Schd (Schedule) Menu (1 of 1)
Section LT
D
INST ADV
Range
Access
Level
Description Item Field
USER
NONE, TMPY Occ Ovr,
PERM Occ Ovr, TMPY
UnOcc Ovr, PERM
UnOcc Ovr, AWAY
Default = NONE
7DAY24hr
Default = 7DAY
The type of setback override that is in effect for all
schedules.
DIP switch = Setback
AWAY is available even if DIP switch ≠ Setback
Selects the same schedule for each day of the week, or
a separate schedule for each day of the week.
DIP switch = Setback
C
C
C
C
C
C
– –:– – to 11:50 PM or
– –:– – to 23:50
Default = – –:– –
– –:– – to 11:50 PM or
– –:– – to 23:50
Default = – –:– –
– –:– – to 11:50 PM or
– –:– – to 23:50
Default = – –:– –
– –:– – to 11:50 PM or
– –:– – to 23:50
Default = – –:– –
Time when the first occupied period begins on Saturday.
7DAY/24h = 7DAY
DIP switch = Setback
Time when the first unoccupied period begins on Saturday.
7DAY/24h = 7DAY
DIP switch = Setback
Time when the second occupied period begins on Saturday.
7DAY/24h = 7DAY
DIP switch = Setback
Time when the second unoccupied period begins on Saturday.
7DAY/24h = 7DAY
DIP switch = Setback
C
C
C
C
Occ 2
UnOcc 2
– –:– – to 11:50 PM or
– –:– – to 23:50
Default = – –:– –
– –:– – to 11:50 PM or
– –:– – to 23:50
Default = – –:– –
– –:– – to 11:50 PM or
– –:– – to 23:50
Default = – –:– –
Time when the first occupied period begins every day.
7DAY/24h = 24hr
DIP switch = Setback
Time when the first unoccupied period begins every day.
7DAY/24h = 24hr
DIP switch = Setback
Time when the second occupied period begins every day.
7DAY/24h = 24hr
DIP switch = Setback
Time when the second unoccupied period begins every day.
7DAY/24h = 24hr
DIP switch = Setback
– –:– – to 11:50 PM or
– –:– – to 23:50
Default = – –:– –
Occ 1
UnOcc 1
Occ 2
UnOcc 2
Occ 1
UnOcc 1
Schd
1
AM
Occ
Occ 1
From 6:00 am to 8:00 am
is the first occupied event.
Occ
Schd
1 Un
AM
UnOcc 1
From 8:00 am to 5:00 pm is
the first unoccupied event.
Occ
Schd
2
PM
Occ 2
From 5:00 pm to 10:00 pm is
the second occupied event.
Occ Un
Schd
2
PM
UnOcc 2
From 10:00 pm to 6:00 pm is
the second unoccupied event.
During a schedule, the two occupied and two unocccupied events follow a sequence. The schedule must be set properly in order for the
events to occur as desired.
Each event must be set to occur after the previous event in the following order:
Example:
Note: To skip an event during a schedule, select the “Null” event. Use the arrow keys to select the “Time” between 11:50 PM and 12:00 AM.
“– –:– –” is displayed indicating that the event will not occur during the schedule.
