Cleaning

The control’s exterior can be cleaned using a damp cloth. Moisten cloth with water and wring out prior to wiping control. Do not use
solvents or cleaning solutions.

DIP Switch Settings

The DIP Switch settings on the control are very important and should be set to the appropriate
settings prior to making any adjustments to the control through the user interface. The DIP switch
settings change the items that are available to be viewed and/or adjusted in the user interface.

LOCK / UNLOCK

The

Lock / Unlock DIP switch is used to lock and unlock the access level of the control and tekmar Net ™ tN1 / tN2 device(s). Once

locked, access levels cannot be changed. To determine if the control is currently locked or unlocked, a small segment representing
a padlock is viewed in the bottom right hand corner of the display. When the padlock is closed, the access level cannot be changed.

To change the access level, set the DIP switch to the unlocked or down position. The current access level of the control or

tekmar

Net™ (tN1/2) device is viewed in its Miscellaneous (Misc) menu. While viewing the access level, use the up and down keys to select
between the Limited (LTD), User (USER), Installer (INST), or Advanced (ADV) access levels.

To lock the access level, select the appropriate access level in the Miscellaneous (Misc) menu and move the DIP switch from the
unlocked position to the locked position. As long as the DIP switch is in the locked position, the access level of the control or tekmar
Net™ (tN1 / tN2) device can no longer be viewed or adjusted in its Miscellaneous (Misc) menu.

SETBACK / NONE

The

Setback / None DIP switch enables and disables the setback functions of the control. When the DIP switch is set to the None

or down position, the control ignores any external setback signal, and its user interface does not display the

Unoccupied adjustments.

When the DIP switch is set to the

Setback position, the internal clock in the control is enabled. The control also responds to an external

setback signal generated on the

UnO Sw terminal.

Access Levels

The tekmar Zone Control 369 comes with four Access Level settings. These Access Levels restrict the number of Menus, Items, and
Adjustments that can be accessed by the user. The four access levels are Limited (LTD), User (USER), Installer (INST) and
Advanced (ADV).

The access level of the control is found in the Miscellaneous (Misc)
menu when the

Lock/Unlock DIP switch is set to the unlocked position.

In the Advanced access level, all of the control settings are available to
the user. In the User access level, only a few of the menus and items
are available. The Limited access level is the most restricted of them all.
The control’s factory setting is Installer (INST). This access level is
sufficient for the normal set up of the control. Once the control is set up,
the appropriate access level should be selected for the people that deal
with the control on a regular basis.
