tekmar 033 4 Timer - Manual

1 of 12 © 2007 D 033 - 10/07
D 033
10/07 tekmarNet ® 4 Timer 033
- Data Brochure
Information
Brochure
Choose controls
to match
application
1
Application
Brochure
Design your
mechanical
applications
2
Rough In
Wiring
Rough-in
wiring
instructions
3
Wiring
Brochure
Wiring and
installation of
specific control
4
Job
Record
Record settings &
wiring details for
future reference
6
Data
Brochure
Control settings
and sequence of
operation
5
tN4 Communication Compatible
Up to 4 Programmable Setback Schedules
Daylight Savings Time
Batteryless Backup •
•
•
• 2 or 4 Events Per Schedule
Backlight
CSA and C US Approved for use in USA
and Canada •
•
•
The tekmarNet ® 4 Timer 033 can be programmed to operate up to four events each day (Wake, Unoccupied, Occupied,
and Sleep). When used in a tekmarNet ® 4 system it can operate up to four separate schedules for one system. It can also
be used as a stand alone Timer by utilizing the relay contact (either normally closed or normally open).
Introduction
Features
