Units Description Definition
5 Signed
Analog, 0 to
10V For a signed value, such as temperature, that is to be converted to a voltage out value. Use
null to set the start point and span to define the range. The null value is the starting
temperature to be associated with 0V. The span is the entire temperature range that is to be
associated with 0 to 10V.
LCD: 0.00V–10.00V
6 Signed
Analog, 0 to
20 mA For a signed value, such as temperature, that is to be converted to a mA out value. Use null to
set the start point and span to define the range. The null value is the starting temperature to
be associated with 0 mA. The span is the entire temperature range that is to be associated with
0 to 20 mA.
LCD: 0.00mA–20.00mA
7 Unsigned
Analog, 0 to
20 mA For unsigned values, such as a counter, that is to be converted to a mA out value. Use the null
to set the start point and span to define the range. The null value is the distance to be
associated with 0 mA. The span is the entire distance range that is to be associated with 0 to
20 mA.
LCD: 0.00mA–20.00mA
8 Signed
Analog, 4 to
20 mA (A) In older models, this units type is for degree Celsius conversions only. Use null to set the start
point and span to define the range. The null value is the starting temperature to be associated
with 4 mA. The span is the entire temperature range that is to be associated with 4 to 20 mA.
For newer firmware models, type codes 8 and 9 are treated the same.
LCD: 4.00mA–20.00mA
9 Signed
Analog, 4 to
20 mA (B) In older models, this units type is for degree Fahrenheit conversions only. Use null to set the
start point and span to define the range. The null value is the starting temperature to be
associated with 4 mA. The span is the entire temperature range that is to be associated with 4
to 20 mA. For newer firmware models, type codes 8 and 9 are treated the same.
LCD: 4.00mA–20.00mA
10 Unsigned
Analog, 0 to
10V For an unsigned value, such as 0 to 20 mA, that is to be converted to a voltage out value. Use
the null to set the start point and span to define the range. The null value is the distance to be
associated with 0V. The span is the entire distance range that is to be associated with 0 to 10V.
LCD: 0.00V–10.00V
11 Counter, 16-
bit The 16-bit counter value records counts up to 65535.
LCD: 0000
12 Unsigned
Analog, 4 to
20 mA For an unsigned value, such as 0 to 10V, that is to be converted to a mA out value. Use the null
to set the start point and span to define the range. The null value is the distance to be
associated with 4 mA. The span is the entire distance range that is to be associated with 4 to
20 mA.
LCD: 4.00mA–20.00mA
