Type # Description Type # Description Type # Description
Hex Dec Hex Dec Hex Dec
0x47 71 10 Ohm RTD (3-wire) IN
1 0xC5 197 Thermocouple E1 0xD1 209 Thermocouple N1
0x48 72 10 Ohm RTD (3-wire) IN
2 0xC6 198 Thermocouple E2 0xD2 210 Thermocouple N2
0x49 73 10 Ohm RTD (3-wire) IN
3 0xC7 199 Thermocouple E3 0xD3 211 Thermocouple N3
0x4A 74 10 Ohm RTD (3-wire) IN
4 0x53 83 Thermocouple E4 0x57 87 Thermocouple N4
0x40 64 100 Ohm RTD (3-wire) IN
1 0xC8 200 Thermocouple G1 0xD4 212 Thermocouple P1
0x41 65 100 Ohm RTD (3-wire) IN
2 0xC9 201 Thermocouple G2 0xD5 213 Thermocouple P2
0x42 66 100 Ohm RTD (3-wire) IN
3 0xCA 202 Thermocouple G3 0xD6 214 Thermocouple P3
0x43 67 100 Ohm RTD (3-wire) IN
4 0x54 84 Thermocouple G4 0x58 88 Thermocouple P4
0x3C 60 Thermistor IN 1 0x34 52 Thermocouple J1 0x44 68 Thermocouple R1
0x3D 61 Thermistor IN 2 0x35 53 Thermocouple J2 0x45 69 Thermocouple R2
0x3E 62 Thermistor IN 3 0x36 54 Thermocouple J3 0x46 70 Thermocouple R3
0x3F 63 Thermistor IN 4 0x4D 77 Thermocouple J4 0x47 71 Thermocouple R4
0x5C 92 Thermistor IN 5 0x38 56 Thermocouple K1 0xD7 215 Thermocouple S1
0xBC 188 Thermocouple B1 0x39 57 Thermocouple K2 0xD8 216 Thermocouple S2
0xBD 189 Thermocouple B2 0x3A 58 Thermocouple K3 0xD9 217 Thermocouple S3
0xBE 190 Thermocouple B3 0x4E 78 Thermocouple K4 0x59 89 Thermocouple S4
0x50 80 Thermocouple B4 0xCB 203 Thermocouple L1 0xDA 218 Thermocouple T1
0xBF 191 Thermocouple C1 0xCC 204 Thermocouple L2 0xDB 219 Thermocouple T2
0xC0 192 Thermocouple C2 0xCD 205 Thermocouple L3 0xDC 220 Thermocouple T3
0xC1 193 Thermocouple C3 0x55 85 Thermocouple L4 0x5A 90 Thermocouple T4
0x51 81 Thermocouple C4 0xCE 206 Thermocouple M1 0xDD 221 Thermocouple U1
0xC2 194 Thermocouple D1 0xCF 207 Thermocouple M3 0xDE 222 Thermocouple U2
0xC3 195 Thermocouple D2 0xD0 208 Thermocouple M3 0xDF 223 Thermocouple U3
0xC4 196 Thermocouple D3 0x56 86 Thermocouple M4 0x5B 91 Thermocouple U4
Host Controller Systems
27
