to 150 will detect only trucks of a specific size. Magnetic field fluctuations vary based on the amount of ferrous metal
present and the distance from the sensor.
If the threshold parameter is 0, there is no threshold and the analog input will report based on the delta rate. Value range:
0 (disable, default) through 65535 (two-byte value). (Threshold parameter number 0x08; Hysteresis parameter number
0x09).
6.2.1 I/O Types (Parameter 0x02)
The following inputs and output types are set using Device Config > Device Parameters screen of the User Configuration
Tool. You may also configure the I/O by sending Modbus commands from your host system.
6.2.1 Input Types
The following are the general input types.
Type # Description Type # Description Type # Description
Hex Dec Hex Dec Hex Dec
0x30 48 Analog IN 1 0x01 1 NPN IN 1 0x19 25 Multiple Discrete NPN
0x31 49 Analog IN 2 0x03 3 NPN IN 2 0x1A 26 Multiple Discrete PNP
0x32 50 Analog IN 3 0x05 5 NPN IN 3 0x3B 59 SDI 12 COMMs
0x33 51 Analog IN 4 0x07 7 NPN IN 4 0xB1 177 Serial Read
0x1B 27 NPN IN 5 0xB2 178 Serial Write
0x0D 13 Async Counter 1 0x1D 29 NPN IN 6 0x37 55 Battery voltage
0x0E 14 Async Counter 2 0x1F 31 NPN IN 7 0xF0 240 Constant
0x0F 15 Async Counter 3 0x21 33 NPN IN 8 0xB3 179 Force sample/report
0x10 16 Async Counter 4 0x02 2 PNP IN 1 0xB4 180 Set threshold with offset
0x04 4 PNP IN 2 0xA3 163 Frequency read
0x4B 75 Bridge IN 1 0x06 6 PNP IN 3 0xA0 160 M-GAGE
0x4C 76 Bridge IN 2 0x08 8 PNP IN 4 0xA1 161 M-GAGE baseline
0x1C 28 PNP IN 5 0xA7 167 M-GAGE configure
0x09 9 Pulse Input 1 0x1E 30 PNP IN 6 0xA4 164 M-GAGE X-Axis
0x0A 10 Pulse Input 2 0x20 32 PNP IN 7 0xA5 165 M-GAGE Y-Axis
0x22 34 PNP IN 8 0xA6 166 M-GAGE Z-Axis
0xB0 176 Clear async counter 0xB5 181 Extended Input Logic
0xAF 175 Clear sync counter 0xA2 162 Enable RTS
6.2.1 Input Temperature Types
The following inputs types are specific to temperature inputs.
