PC / MAC Assistant
© 2014 DJI. All Rights Reserved.
47
An internet connection is required to upgrade the Phantom 2 Vision+ firmware.
DO NOT power off until the upgrade is finished.
If the firmware upgrade fails, the Flight Controller will enter a waiting for firmware upgrade status automatically.
If this happens, repeat the above procedures.
Firmware upgradable items: (1)Flight Controller (2)GPS (3)5.8G Receiver (4) Main Board (P330CB) (5)Battery (6)
Gimbal IMU
2.3 Using the Phantom RC Assistant
Use the Phantom 2 Vision+ Assistant to install PHANTOM RC Assistant on your Windows PC or Mac, and then follow the
below steps to configure the Remote Control.
Firmware upgradable items
Current firmware version
Upgrade link
* This image is for reference
only. Please refer to the
actual user interface.
Figure 113
Figure 114
(1) Turn off the Remote Control and find its Micro-USB slot.
(2) Power on PC and Remote Control then connect Remote Control to the PC with a Micro-USB cable. DO NOT
disconnect until configuration is finished.
(3) Run the PHANTOM RC Assistant and wait for the Remote Control to connect to Assistant. Watch the indicators
on the bottom left of the screen. When connected successfully, the Computer Connection status is and Data
Exchange Indicator blinks .
(4) Finish configuration in the [Main] page.
(5) Finish upgrade in the [Info] page if necessary.
Main page
Data Exchange Indicator
Computer Connection status
Language swap
Firmware upgrade,
Account, Software version
*This image is for reference only.
Please refer to the actual user
interface.
Figure 115
Using Assistant
