Flight
©
2014 DJI. All Rights Reserved.
31
Ready to Fly
Green flashing
Zone
Restriction
DJI VISION App Notification
Rear LED
Flight Indicator
No-fly Zone
Motors will not start.
Warning: You are in a No-fly zone. Take off
prohibited.
Red flashing
If the Phantom enters the restricted
area in Ready to Fly (non-GPS) mode
but Ready to Fly mode activates, the
Phantom will automatically descend to
land then stop its motors after landing.
Warning: You are in a No-fly zone, automatic
landing has begun. (If you are within 1.5 mile
radius)
Restricted-altitude
flight zone
If the Phantom enters a restricted area
in Ready to Fly (non-GPS) mode and
Ready to Fly mode activates, it will
descend to a safe altitude and hover 15
feet below the safe altitude.
Warning: You are in a restricted zone.
Descending to safe altitude. (If you are between
the range of 1.5 mile and 5 mile radius)
Warning: You are in a restricted zone. Max flight
height restricted to between 10.5m and 120m.
Fly Cautiously.
Warning zone
No flight restriction applies, but there
will be warning message.
Warning: You are approaching a restricted
zone, Fly Cautiously.
Free zone
No restrictions.
None.
None.
Semi-automatic descent: All stick commands are available except the throttle stick command during the
descent and landing process. Motors will stop automatically after landing. Users must toggle the S1 switch to
When flying in the safety zone, LED flight indicators will blink red
quickly and continue for 3 seconds,
then switch to indicate current flying status and continue for 5 seconds at which point it will switch back to red
blinking.
For safety reasons, please do not fly close to airports, highways, railway stations, railway lines, city centers and
other special areas. Try to ensure the aircraft is visible.
Figure 59:Category A
Figure 60: Category B
Category A Safety Zone
(1) The category A “safety zone” is comprised of a small “no-fly zone” and a range of “restricted-altitude zones”. Flight
is prevented in the “no-fly zone” but can continue with height restrictions in the restricted-altitude zone.
(2) 1.5 miles (2.4 km) around a designated safety zone is a no-fly zone, inside which takeoff is prevented.
(3) 1.5 miles (2.4 km) to 5 miles (8 km) around restricted areas are altitude restricted, with maximum altitude going from
35 feet (10.5 m) at 1.5 miles (2.4 km) to 400 feet (120 m) at 5 miles (8 km).
(4) A “warning zone” has been set around the safety zone. When you fly within 320 feet (100m) of the safety zone, a
warning message will appear on the DJI Vision app.
Category B Safety Zone
(1) Category B “safety zone” is comprised of a “no-fly zone” and a “warning zone”.
(2) 0.6 miles (1 km) around the safety zone is a designated “no-fly zone”.
(3) A “warning zone” has been set around the safety zone. When you fly within 0.6 miles (1Km) of this zone, a warning
will appear on the DJI Vision app.
Flight Limits
