INSTALLATION
INSTRUCTIONS
9581 Instructions 4-18-13.doc 12 of 13
Step 67. Remove three screws from driver’s side sun
visor with a T15 Torx driver.
Step 68. Remove the bolt cover on the driver’s side A-
Pillar using a Pick Tool. Insert the pick into the gap
between the bolt cover and A-pillar cover. Gently pry the
bolt cover away from the A-pillar cover while being
careful not to damage the trim.
Step 69. Remove the driver’s side A-pillar bolt using a
7mm socket and then remove the A-pillar cover.
Step 70. Remove the driver’s side A-pillar with a Pick
Tool.
Step 71. Tape the wiring shield to the headliner.
Step 72. Route Mirror Harness under leading edge of
the driver’s side headliner by gently separating the
headliner from the windshield and tucking the harness
into the gap with your fingers.
