50
Model Connector Dim. A
1
Dim. B Dim. C
Inner
Conduc
tor
Setback
Weight
BPME1 1-5/8” EIA
Flanged 3.50”
(89 mm) 6.75”
(171.5 mm) 2.98“
(75.7 mm) EIA 3.25 lbs.
(1.5 kg)
BPME1U 1-5/8” EIA
Unflanged 1-5/8”
(41.3 mm) 6.38”
(162 mm) 2.98“
(75.6 mm) 0.438”
(11.1 mm) 1.5 lbs.
(0.68 kg)
BPME1UF 1-5/8” EIA
Unflanged,
Flush Center 1-5/8”
(41.28 mm) 6.38”
(162 mm) 2.98“
(75.6 mm) 0 1.5 lbs.
(0.68 kg)
BPME3 3-1/8” EIA
Flanged 5.19”
(132 mm) 7.03”
(178.6 mm) 3.4“
(86.4 mm) EIA 7.25 lbs.
(3.3 kg)
BPME3U 3-1/8” EIA
Unflanged 3-1/8”
(79.4 mm) 6.5”
(165.1 mm) 3.4“
(86.4 mm) 0.688”
(17.5 mm) 4.25 lbs.
(1.93 kg)
BPME3UF 3-1/8” EIA
Unflanged,
Flush Center 3-1/8”
(79.4 mm) 6.5”
(165.1 mm) 3.4“
(86.4 mm) 0 4.25 lbs.
(1.93 kg)
BPME4AUF 4-1/2” IEC
Unflanged
4.17”
(106 mm) 7.5”
(190.5 mm) 3.96”
(100.7 mm) 0.06”
(1.5 mm) 10 lbs.
(4.55 kg)
BPME4D 4-1/16”
Flanged,
Dielectric
Standard 6.19”
(157 mm) 8.38”
(212.8 mm) 3.87“
(98.2 mm) 1.22”
(31 mm) 8.88 lbs.
(4 kg)
BPME4M 4-1/16”
Flanged,
Myat
Standard 6.19”
(157 mm) 8.38”
(212.8 mm) 3.87“
(98.2 mm) 1.375”
(35 mm) 8.88 lbs.
(4 kg)
BPME6 6-1/8” EIA
Flanged 8.13”
(206 mm) 10.22”
(259.6 mm) 4.96“
(126 mm) EIA 17 lbs.
(4 kg)
BPME6U 6-1/8” EIA
Unflanged 6-1/8”
(155.6 mm) 9.63”
(244.6 mm) 4.96“
(126 mm) 0.968”
(24.6 mm) 12.75 lbs.
(5.78 kg)
BPME7 7/8” line,
Type N
connectors 1.25”
(318 mm) n/a n/a n/a 1.25 lbs.
(0.57 kg)
1
For unflanged units, this dimension is the outer diameter of the transmission line.
