45
RF Power Range, VHF Frequency Band (45-230 MHz)
Remote Computer Connector
Connector
Protocol Female DB-9
RS-232, 9600 baud, no parity, 8 data bits,
1 stop bit, no handshake
AC Power Requirements 115/230 Vac @ 50/60 Hz, 0.6 A
AC Connector
Domestic
International
North American Power Cord Standard
Type SVT, 300 Vac, 18 AWG, 10 A, 3
conductor (including ground)
Type H05VV-F, 300 Vac, 1.00 mm, 10 A,
3 conductor (including ground)
Temperature
Operating
Storage –10 to +50 °C (+14 to 122 °F)
–40 to +80 °C (–40 to +176 °F)
Humidity 95% max. (non-condensing)
Altitude 3000 m (10,000 ft.)
Dimensions 19" L x 1.75" W x 5" H
(483 x 44 x 127 mm) (1U EIA)
Weight, Nominal < 10 lbs
Line size
Unit power
range
Measurable
Range, Fwd
Measurable
Range, Rfl
7/8” High
Med
Low 5000 - 50 W
2000 - 20 W
500 - 5 W 500 - 5 W
200 - 2 W
50 - 0.5 W
1-5/8” High
Med
Low 20 - 0.2 kW
8000 - 80 W
2000 - 20 W 2000 - 20 W
800 - 8 W
200 - 2 W
3-1/8” High
Med
Low
Extra Low 50 - 0.5kW
20 - 0.2 kW
5000 - 50 W
1000 - 10 W 5000 - 50 W
2000 - 20 W
500 - 5 W
100 - 1 W
4-1/16” and
4-1/2” High
Med
Low 100 - 1 kW
40 - 0.4 kW
10 - 0.1 kW 10 - 0.1 kW
4000 - 40 W
1000 - 10 W
6-1/8” High
Med
Low 200 - 2 kW
80 - 0.8 kW
20 - 0.2 kW 20 - 0.2 kW
8000 - 80 W
2000 - 20 W
