21
3. Apply operating power to the BPM-E. Refer to "BPM-E Data Connections"
on page 17).
4. Launch PCTool from your hard drive.
5. Specify which COM (serial) port the BPM-E will use:
a. On the Menu bar, click on Connection and select New....
b. On the New Connection dialog box, select the computer
COM port to which the BPM-E is connected then click OK
(Figure 12, page 21).
Note: When the BPM-E establishes communication with your PC, the
PCTool software will display the COM port being used in the space
immediately below the Menu bar.
Note: To use the features of the PCTool software, refer to
Chapter 4 Operating Instructions on page 27.
Figure 12 PCTool, Select a COM Port
WARNING
Dangerous RF voltage. Do not connect or apply an RF signal to the BPM-E
during equipment setup. Failure to comply may result in severe burns, loss of
use of limbs, or death.
WARNING
Do not connect RF power to the unit.
