Mode Button
Press MODE to cycle through the possible display modes for the right half of the
display, which are:
•
Reflected Power
•
Match Efficiency (%)
•
Return Loss (dB)
•
VSWR (SWR)
•
Reflection Coefficient ( ρ)
Units Button
Press UNITS to toggle the display between Watts (W or kW) and dBm. The unit applies
to forward power and to reflected power (if it is displayed).
Reset Button
Resets the alarm LED if the alarm condition is no longer present. Directly connected to
the Reset Input pin of the BPM-E Power/Alarm connector.
Alarm LED
Indicates the presence of an alarm condition. Directly connected to the Alarm
pin on the BPM-E Power/Alarm connector.
WebTool Software
The BPM-E WebTool software is used to monitor the measurement outputs from
the BPM-E and to set and change alarm and network configurations. This soft-
ware runs in a web browser (such as Microsoft’s Internet Explorer). To use the
tool, open a web browser then in the address field, type the address of the
BPM-E you wish to access. The software has five buttons at the left side that
open the following screens: Main, Stats, Config, Admin, and Help. You can access
information about the WebTool software by click on the Help button.
