Chapter 3 Installation
This chapter provides information for preparing the Bird Broadcast Power Moni-
tor for use.
Unpacking and Inspection
1. Carefully inspect the shipping container for signs of damage. If damage is
noticed, do not unpack the unit. Immediately notify the shipping carrier and
Bird Electronic Corporation.
2. If the shipping container is not damaged, unpack the unit. Save the packing
material in case the unit needs to be shipped again.
3. Inspect all of the components for visible signs of damage. Immediately
notify the shipping carrier and Bird Electronic Corporation of equipment
damage or missing parts.
The Bird BPM-E is shipped complete and ready for use upon receipt. After
unpacking and inspecting the unit, it is ready to be installed.
Tools Required
You will need only common hand tools to install the BPM-E and the 3129 Digital
Display (if used).
Mounting a BPM-E
Make sure that the LEDs and reset button are accessible, and that the connect-
ing cables have adequate clearance. Mount the BPM-E in the transmission line
between the transmitter and the antenna. “In” or “RF Input” is the signal from
your transmitter. “RF Output” is the signal going to the antenna or load. Follow
the instructions in this section to mount a BPM-E7 (See “BPM-E7” on page 12), a
BPM-E with a flanged connector (See “Flanged Connector” on page 13), or a
BPM-E with an unflanged connector (See “Unflanged Connector” on page 13).
Be sure to connect the BPM-E to the RF line as described.
WARNING
Leaking RF energy is a potential health hazard. Never attempt to connect or
disconnect equipment from the transmission line while RF power is being
applied. Severe burns, electrical shock, or death can occur.
