PMI A/B Status Register
The PMI A/B Status register contains bits which describe any errors or warnings reported by the PMI
related to UDC/PMI communication on PMI A and PMI B. These bits are latched when set and will
remain set until a fault reset or warning reset is issued.
Bit: 0
Hex Value:
0001 H
Sug. Var. Name:
N/A
Range:
N/A
Access:
Read only
UDC Error Code:
N/A
LED:
N/A
Description: The Invalid Receive Interrupt bit is set when the interrupt generated by the Universal Se-
rial Controller (USC) is not properly marked.
Bit:
1
Hex Value: 0002H
Sug. Var. Name:
N/A
Range:
N/A
Access:
Read only
UDC Error Code:
N/A
LED:
N/A
Description:
The No End of Frame Status Received bit is set if the USC does not report an End of
Frame condition when the receive interrupt is generated.
Bit: 2
Hex Value: 0004H
Sug. Var. Name:
N/A
Range:
N/A
Access:
Read only
UDC Error Code:
N/A
LED:
N/A
Description:
The CRC/Framing Error bit is set when the USC reports a CRC or Framing error on the
last frame (message) received.
Bit: 3
Hex Value: 0008H
Sug. Var. Name:
N/A
Range:
N/A
Access:
Read only
UDC Error Code:
N/A
LED:
N/A
Description:
The Overrun Error bit is set when the USC reports a receive first-in, first-out overrun.
Bit: 4
Hex Value: 001
OH
Sug. Var. Name:
N/A
Range:
N/A
Access:
Read only
UDC Error Code:
N/A
LED:
N/A
Description:
The DMA Format Error bit is set if the length of the received message does not match
the length encoded in the message itself.
