Field Power Status Integers
The variables in the rack of field power status integers (all DINT) provide information
to the application about the field power supplies to a group of digital output modules.
Group Field Power Current
Direction: input to application from controller
Type: DINT
Values:
0 to 8,000mA or greater (limited by capacity of DINT variable)
Description:
Reports the total current that all the active digital output modules in a group are
drawing from the field power supply. Accuracy is ± 10%.
A Module Field Power Voltage 1
Direction: input to application from controller
Type: DINT
Values:
0 to 48,000mV or greater (limited by capacity of DINT variable)
Description:
Reports the voltage from the field power supply, for the specified module and field
power input. Accuracy is ± 500mV.
A Module Field Power Voltage 2
Direction: input to application from controller
Type: DINT
Values:
0 to 48,000mV or greater (limited by capacity of DINT variable)
Description:
Reports the voltage from the field power supply, for the specified module and field
power input. Accuracy is ± 500mV.
B Module Field Power Voltage 1
Direction: input to application from controller
Type: DINT
Values:
0 to 48,000mV or greater (limited by capacity of DINT variable)
Description:
Reports the voltage from the field power supply, for the specified module and field
power input. Accuracy is ± 500mV.
