Demo Unit User Manual (AADvance Controller)
1-6 Document: 553850 Issue 1.2: March 2011
Processor Module Specification
Table 1: Processor Module Specification
Attribute Value
Functional Characteristics
Degradation 1oo1D, 1oo2D and 2oo3D
Processor clock 400MHz
Memory
Boot flash 512kB
SRAM 512kB
Bulk flash 64MB
SDRAM 32MB
Sequence of Events
Event Resolution Application Scan
Time-stamp Accuracy 5ms
Performance Characteristics
Safety Integrity Level (SIL) One module — non-safety applications, SIL1
and/or SIL2 safety applications
Two modules — SIL3 applications
Three modules — SIL3 fault tolerant and TMR
applications
Electrical Characteristics
Supply Voltage Redundant + 24V dc nominal; 18V dc to 32V
dc range
Power consumption (from 24V dc supply
to controller)
6W
Heat dissipation 6W
Maximum Surface Temperature of Module 43°C ± 2°C
Mechanical Specification
Dimensions (height × width × depth) 166mm × 42mm × 118mm
(6-½ in. × 1-5/8 in. × 4-5/8 in.)
Weight 430g (15 oz.)
Casing Plastic, non-flammable
