Publication GMSI10-UM006C-EN-P - August 2010
DeviceNet Objects 87
Instance 199 - Dynamic Assembly
This Assembly instance can be created and configured with the XM Serial
Configuration Utility or RSMACC Enterprise Online Configuration Utility.
Using the configuration software, you determine the format of the data. This
assembly instance can be selected to be sent in response to an I/O Poll request
from a Master.
The dynamic Assembly can include all of the measurement values included in
Assembly instance 101. In addition, the dynamic Assembly can include the
following configuration parameters.
The dynamic Assembly instance must be instantiated with a call to the class
level Create service. Then the structure can be defined with the
Set_Attribute_Single service for the Member List attribute. Only one dynamic
Attribute instance is supported so subsequent calls to the Create service will
return a Resource Unavailable (0x02) error. The Delete service can be used to
destroy the dynamic Assembly instance so that it can be re-created.
Table C.14 Instance 199 Component Mapping
EPATH (where ii =
instance number) Class
Name Class
Number Instance
Number Attribute
Name Attribute
Number Data
Type
21 1D 03 24 ii 30 04 Alarm 31D
h
1 - 18 Alarm Enable 4 BOOL
21 1D 03 24 ii 30 07 Alarm 31D
h
1 - 18 Condition 7 USINT
21 1D 03 24 ii 30 08 Alarm 31D
h
1 - 18 Alert Threshold (High) 8 REAL
21 1D 03 24 ii 30 09 Alarm 31D
h
1 - 18 Danger Threshold
(High) 9 REAL
21 1D 03 24 ii 30 0A Alarm 31D
h
1 - 18 Alert Threshold Low 10 REAL
21 1D 03 24 ii 30 0B Alarm 31D
h
1 - 18 Danger Threshold Low 11 REAL
21 1D 03 24 ii 30 0C Alarm 31D
h
1 - 18 Hysteresis 12 REAL
21 23 03 24 ii 30 04 Relay 323
h
1 - 8 Relay Enable 4 BOOL
21 23 03 24 ii 30 05 Relay 323
h
1 - 8 Latch Enable 5 BOOL
21 23 03 24 ii 30 06 Relay 323
h
1 - 8 Failsafe Enable 6 BOOL
21 23 03 24 ii 30 07 Relay 323
h
1 - 8 Delay 7 UINT
21 23 03 24 ii 30 09 Relay 323
h
1 - 8 Alarm Level 9 BYTE
21 0F 00 24 ii 30 01 Param 0F
h
7 - 14 Parameter Value
(Alarm Identifier A) 1 USINT
21 0F 00 24 ii 30 01 Param 0F
h
15 -22 Parameter Value
(Alarm Identifier B) 1 USINT
21 23 03 24 ii 30 0C Relay 323
h
1 - 8 Logic 12 USINT
21 23 03 24 ii 30 0E Relay 323
h
1 - 8 Relay Installed 14 BOOL
