Rockwell Automation 1440-TPR06-00RE XM-360 Process Module - Manual (Page 26)

Publication GMSI10-UM006C-EN-P - August 2010
18 Installing the XM-360 Process Module
3 Input RTN 1 Current return when channel configured as a loop current
input
Redundant terminal used to jumper terminal to channel Vin (-)
terminal, a requirement for loop current input
4 Input RTN 1
5 Input RTN 2 Current return when channel configured as a loop current
input
Redundant terminal used to jumper terminal to channel Vin (-)
terminal, a requirement for loop current input
6 Input RTN 2
7 Input RTN 3 Current return when channel configured as a loop current
input
Redundant terminal used to jumper terminal to channel Vin (-)
terminal, a requirement for loop current input
8 Input RTN 3
9 Input RTN 4 Current return when channel configured as a loop current
input
Redundant terminal used to jumper terminal to channel Vin (-)
terminal, a requirement for loop current input
10 Input RTN 4
11 Input RTN 5 Current return when channel configured as a loop current
input
Redundant terminal used to jumper terminal to channel Vin (-)
terminal, a requirement for loop current input
12 Input RTN 5
13 Input RTN 6 Current return when channel configured as a loop current
input
Redundant terminal used to jumper terminal to channel Vin (-)
terminal, a requirement for loop current input
14 Input RTN 6
15 Chassis Connection to DIN rail ground spring or panel mounting hole
16 4-20mA 1 (+) 4-20mA output 1, positive side
17 4-20mA 2 (+) 4-20mA output 2, positive side
18 4-20mA 3 (+) 4-20mA output 3, positive side
19 Vin (+) / Input In 1 Voltage Input 1, positive side when channel configured as a
voltage input
Current Input 1 when channel configured as a current input
20 Vin (-) / Iin Sense 1 Voltage Input 1, negative side when channel configured as a
voltage input
Current sensing 1 terminal when channel configured as a
current input, must be jumpered to channel Input RTN
21 Vin (+) / Input In 2 Voltage Input 2, positive side when channel configured as a
voltage input
Current Input 2 when channel configured as a current input
22 Vin (-) / Iin Sense 2 Voltage Input 2, negative side when channel configured as a
voltage input
Current sensing 2 terminal when channel configured as a
current input, must be jumpered to channel Input RTN
23 Vin (+) / Input In 3 Voltage Input 3, positive side when channel configured as a
voltage input
Current Input 3 when channel configured as a current input
Terminal Block Assignments
No. Name Description
