Installing the XM-360 Process Module 19
24
Vin (-) / Iin Sense 3
Voltage Input 3, negative side when channel configured as a
voltage input
Current sensing 3 terminal when channel configured as a
current input, must be jumpered to channel Input RTN
25
Vin (+) / Input In 4
Voltage Input 4, positive side when channel configured as a
voltage input
Current Input 4 when channel configured as a current input
26
Vin (-) / Iin Sense 4
Voltage Input 4, negative side when channel configured as a
voltage input
Current sensing 4 terminal when channel configured as a
current input, must be jumpered to channel Input RTN
27
Vin (+) / Input In 5
Voltage Input 5, positive side when channel configured as a
voltage input
Current Input 5 when channel configured as a current input
28
Vin (-) / Iin Sense 5
Voltage Input 5, negative side when channel configured as a
voltage input
Current sensing 5 terminal when channel configured as a
current input, must be jumpered to channel Input RTN
29
Vin (+) / Input In 6
Voltage Input 6, positive side when channel configured as a
voltage input
Current Input 6 when channel configured as a current input
30
Vin (-) / Iin Sense 6
Voltage Input 6, negative side when channel configured as a
voltage input
Current sensing 6 terminal when channel configured as a
current input, must be jumpered to channel Input RTN
31
4-20mA 4 (+)
4-20mA output 4, positive side
32
4-20mA 5 (+)
4-20mA output 5, positive side
33
4-20mA 6 (+)
4-20mA output 6, positive side
34
4-20mA 1 (-)
4-20mA output 1, negative side
35
4-20mA 2 (-)
4-20mA output 2, negative side
36
4-20mA 3 (-)
4-20mA output 3, negative side
37
+24V In
Connection to primary external +24V power supply, positive
side
38
24V Common
Connection to external +24V power supply, negative side
(internally DC-coupled to circuit ground)
39
Reserved
40
Common
Internally DC-coupled to circuit ground
41
Chassis
Connection to DIN rail ground spring or panel mounting hole
42
Chassis
Connection to DIN rail ground spring or panel mounting hole
43
Chassis
Connection to DIN rail ground spring or panel mounting hole
44
CAN_High
DeviceNet bus connection, high differential (white wire)
45
CAN_Low
DeviceNet bus connection, low differential (blue wire)
46
CAN Shield
DeviceNet bus connection to chassis ground (bare wire)
Terminal Block Assignments
No.
Name
Description
