Publication GMSI10-UM006C-EN-P - August 2010
58 Configuration Parameters
Data Parameters
The Data parameters are used to view the measured values of the input
channels and the 4–20mA outputs, as well as to monitor the status of the
channels, alarms, and relays.
Channel Data Parameters
TIP
To view all the data parameters in the XM Serial
Configuration Utility, click the View Data tab.
Channel Data Parameters
Parameter Name
Description
Values/Comments
Channel Status
States whether a fault exists on the associated
channel. If a fault exists, the measurement and rate
of change values may not be accurate.
Possible status values: No Fault
Fault
Shows the current measurement value for the
channel.
Important: Channel 6 data values are
not available if the Enable Relay
Reset Switch Terminals parameter
is enabled. (Refer to General
Parameters on page 44.) The Channel
6 measurement Value will display
"Open" if the measurement value is
<0.5, or "Closed" if the measurement
value is
≥ 0.5.
Shows the current rate of change value for the
channel.
Difference
Shows the current difference value for the channel.
This value is calculated by subtracting the previous
channel's measurement from this channel’s
measurement.
XM
Configuration
Utility
EDS File
Value
Measurement
Value
XM Configuration
Utility
EDS File
Rate
Rate of
Change
