Configuration Parameters 59
Alarm and Relay Status Parameters
Alarm and Relay Status Parameters
Parameter Name Description Values/Comments
Alarm Status States the current status of the measurement value,
rate of change and difference alarm. Possible status values:
• Normal - The alarm is enabled, the
device is in Run mode, there is no
sensor-out-of-range error, and the
current measurement is not within
the Alert or Danger Threshold
value(s).
• Alert - The alarm is enabled, the
device is in Run mode, there is no
sensor-out-of-range error, and the
current measurement is in excess of
the Alert Threshold value(s) but
not in excess of the Danger
Threshold value(s).
• Danger - The alarm is enabled, the
device is in Run mode, there is no
sensor-out-of range error, and the
current measurement is in excess of
the Danger Threshold value(s).
• Disarm-The alarm is disabled or the
device is in Program mode.
• Sensor OOR - The alarm is
enabled, the device is in Run mode,
and a sensor-out-of-range error is
detected for the associated sensor.
• Module Fault - Hardware or
firmware failure, or an error has
been detected and is preventing
proper operation of the device.
Relay Status States the current status of the relay. Possible status values: Activated
Not Activated
