Rockwell Automation 1440-TPR06-00RE XM-360 Process Module User Manual
Page 53

Publication GMSI10-UM006C-EN-P - August 2010
Configuration Parameters 45
Sensor Input Range
Defines the valid range of the input signal.
Options: 0 to 5 Volts
0 to 10 Volts
4 to 20 mA
-5 to 5 Volts
1 to 5 Volts
0 to 20 mA
0 to 1 Volt
Data Units
Defines the data units of the measured value.
High Scale Limit
Sets the output value corresponding to the high end
of the Sensor input range.
Defines how the input signal should
be scaled into a measurement value.
Note: A sensor-out-of-range condition
exists when the output value is
outside this range.
Low Scale Limit
Sets the output value corresponding to the low end
of the Sensor input range.
Channel Parameters
Parameter Name
Description
Values/Comments
Data Units
Options
Quantity of
Measure
Deg C
Deg F
Temperature
PSI
inHg
mbar
Pa
kPa
Pressure
CFM
Flow
m/s2
g
gSE
Acceleration
mA Electrical
Current
RPM
Hz
Frequency
ips
mm/s
Velocity
mm
um (micro
meter)
in
mil
Displacement
V
Voltage
radian
revolution
degree
Rotational Angle
percent
percent
unspecified
unspecified
