Publication GMSI10-UM006C-EN-P - August 2010
64 Specifications
Relays
Number
Failsafe
Latching
Time Delay
Voting Logic
Reset
Activation On
Up to eight relays when interconnected to
one or two XM-441 Expansion Relay
modules, or
Eight virtual relays whose status can be
used by remote control systems
Normally energized (failsafe), or
Normally de-energized (non-fail-safe)
Latching, or
Non-latching
0 to 25.5 seconds, adjustable in 100msec
increments
Single or paired "And" or "Or" logic applied
to any alarm
Local reset switch on top of module
Digital reset command via serial or
DeviceNet interface
Alarm Status:
Normal
Alert
Danger
Disarm
Sensor-out-of-range
Module fault
Non-Volatile Configuration A copy of the module configuration is
retained in non-volatile memory from where
it is loaded upon power up*.
*The configuration stored in non-volatile
memory can be deleted only by a module-reset
command sent via the serial interface, using
the Serial Configuration Utility, or via
DeviceNet from any compliant software
application.
Power
Module
Consumption
Heat Production
+21.6 to 26.4V dc
Maximum: 300mA
Typical: 170mA
Maximum: 7.20 Watts (24.6 BTU/hr)
Typical: 4 Watts (14 BTU/hr)
XM-360 Technical Specifications
Product Feature Specification
