Page 107: Device mode object (class id 320

Publication GMSI10-UM006C-EN-P - August 2010
DeviceNet Objects 99
Services
1
Attributes can only be set while the device is in Program Mode. See the description of the Device Mode Object
for more information.
Device Mode Object
(Class ID 320
H
)
The Device Mode Object is used to control access to the configuration
parameters in the module. This object’s Device Mode attribute must be in
PROGRAM mode to allow the module’s configuration parameters to be "Set"
(see Services). Attempts to set the configuration parameters while the Device
Mode is in RUN mode will return an error. Note that the module collects
measurements while in RUN mode but not while it is in PROGRAM mode.
Class Attributes
The Device Mode Object provides no class attributes.
11
Get/Set
Danger Threshold
Low
REAL
The lesser threshold value
for the danger (shutdown)
condition for the range
condition types.
12
Get/Set
Hysteresis
REAL
The amount on the safe
side of a threshold by
which the value must
recover to clear the alarm.
18
Get/Set
Name
STRING2
A name to help identify
this alarm.
Table C.29 Alarm Object Instance Attributes
Attr ID
Access
Rule
Name Data
Type
Description
Semantics
Table C.30 Alarm Object Services
Service
Code
Class/Instance Usage
Name
Description
0E
h
Instance
Get_Attribute_Single
Returns a single attribute.
10
h
Instance
Set_Attribute_Single
Sets a single attribute.
1
